01 - V2 Backbone
Model the real project.
Represent systems, subsystems, functional objects, groups, relationships, signals, tags and implementation points as one connected engineering structure.
VXT-001 - Governed Engineering Platform
Vextral Governed Engineering
A V2 engineering spine for industrial automation system integrators: functional objects, signals, tags, I/O, standards packs, validation rules, narratives, and controlled deliverables from one governed source of truth.
Model
Systems, functional objects, schemas, signals, tags, I/O and relationships.
Standards
Pack-driven rules for client, platform, naming, validation and document behavior.
Outputs
FDS, I/O lists, alarm schedules, FAT/SAT packs and governed AI-assisted narrative.
01
Platform
Not another document wrapper
Engineering control before document control.
Vextral starts with the engineering model, not the template shell. The functional object is the anchor. Signals, tags, I/O, alarms, control behavior, document sections and validation all hang from governed project truth.
From source truth to controlled issue.
02 - Library Authoring
Author object types and schemas.
Create governed object types like filter, blower or power monitor, then attach schemas and signal patterns beneath them instead of hardcoding new topics into seed routes.
03 - Controlled Outputs
Generate governed deliverables.
Registers, narratives and issue packs stay traceable to the underlying model, active standards context and review state.
02
Workflow
Project context to governed issue
A controlled path through messy automation delivery.
The point is not to type faster. The point is to stop retyping the same engineering truth into five disconnected documents and ten inconsistent registers.
Project Context
Select sector, client, platform, telemetry and package scope.
Pack Binding
Pin exact published standards versions through profiles and binding sets.
Engineering Model
Create systems, functional objects, schemas, signals, tags and relationships.
Validation
Run naming, schema, dependency, alarm, interface and deliverable checks.
Controlled Outputs
Generate, review, approve and issue governed deliverables with traceability.
03
Standards Engine
Packs, bindings and runtime context
Standards should be governed artifacts, not tribal memory.
Vextral treats client standards, industry baselines, platform rules and project overrides as versioned packs. Projects bind to exact versions. Runtime resolves from those pins, not from vague latest behavior.
Pack Registry
Publish immutable standards artifacts with versioning, validation evidence and compatibility metadata.
Binding Sets
Pin each project to exact published pack versions so behavior stays reproducible over time.
Resolved Context
Derivation, validation, narrative and document generation all consume one deterministic standards snapshot.
Upgrade Control
New standards do not silently mutate live projects. Changes arrive as explicit upgrade proposals with impact review.
04
Governed AI
Proposal first, never silent truth mutation
AI should assist engineering, not bypass it.
AI in Vextral runs through declared flight plans, reads V2 project truth plus resolved standards context, and produces drafts, advice or structured proposals. It can help move faster, but it does not get to invent authoritative engineering state.
AI may propose. Engineers still decide.
Drafting Mode
Create candidate section narrative grounded in functional objects, groups, signals and active standards bundles.
Advisory Mode
Explain gaps, validation results and deliverable readiness without mutating the project model.
Import Proposal Mode
Parse project documents into reviewable engineering proposals backed by provenance and confidence, not direct writes.
Knowledge Base
Use imported specifications and project documents as evidence for proposals while keeping source references intact.
05
Outputs
The document is an output, not the source of truth
Registers and deliverables stay connected to the model.
A generated output should know where it came from, which standards context produced it, what changed, and whether it is safe to issue.
Engineering Tree
SRaw Water SystemSystem
SSRaw Water PumpingSubsystem
GRW-PUMP-SET-0013 plus 1
FOP-101 Raw Water Pump 1Duty
FOP-102 Raw Water Pump 2Assist
FOP-104 Raw Water Pump 4Standby
AI Flight Plan
CContext source: resolved V2 snapshotAllowed
PPack basis: UE + platform + projectGrounded
RReview required before authored issueManual
IImport proposal writeback blockedSafe
TTraceability retained to source bundleTracked
Controlled Deliverable Register
| Deliverable | Source | Status | Action |
|---|---|---|---|
| Functional Design Specification | Objects, control functions, alarms, narrative drafts | In Review | Resolve 2 comments |
| I/O List | Signals, tags, I/O points, platform constraints | Current | Ready for issue |
| Alarm Schedule | Alarm definitions, priorities, client rules | Stale | Regenerate required |
| FAT Pack | Signals, test scope, control logic, standards context | Draft | Complete object data |
Early access
Build the project model before the project documents break.
Vextral is being shaped for automation teams that need stronger control over project truth, standards, generated outputs, and governed AI assistance.
